X5 FastMig
Operating manual - EN
Inside wire feeder (wire feeder cabinet)
1. Wire spool
>> For more information on the wire spools, refer to "Wire spools and hubs (300)" on the next page.
2. Wire spool locking cover
3. Wire feed roll mechanism
4. Wire inch button
>> Drive the filler wire forward (with arc off).
5. Gas test button
>> Test the shielding gas flow and flush the gas line.
Inside wire feeder (interconnection cable cabinet)
1. Interconnection cable cabinet door and latch
2. Shielding gas hose connector
3. Control cable connector
4. Welding current cable connector
5. Coolant hose mounting slot
6. Interconnection cable strain relief
With X5 Wire Feeder 300 Auto+ also:
