X5 FastMig
Operating manual - EN
1-MIG welding parameters
The parameters listed here are available for adjustment only with the 1-MIG process.
Parameter Parameter value Description
Upslope
ON/OFF Upslope is a welding function that
determines the time, during which the
welding current gradually increases to
the desired welding current level at the
start of the weld. The upslope start level
and time are preset by the user.
Upslope start level
ON: 10 ... 100 %, step 1
Default = 50
Upslope time
ON: 0.1 ... 5 s, step 0.1
Default = 0.10
Hot start
ON/OFF Welding function that uses higher or
lower wire feed speed and welding cur-
rent at the start of the weld. After the Hot
start period the current changes to nor-
mal welding current level. This facilitates
the start of the weld especially with alu-
minum materials. The Hot start level and
time (only in 2T trigger mode) are preset
by the user.
Hot start level
ON: -50 ... +200 %, step 1
Default = 40
Hot start time
ON: 0.0 ... 9.9 s, step 0.1
Default = 1.2 s
Crater fill
ON/OFF When welding with high power, a crater
is usually formed at the end of the weld.
The Crater fill function decreases the
welding power / wire feed speed at the
end of the welding job so that the crater
can be filled using a lower power level.
With 1-MIG process, Crater fill start level,
duration and end level are preset by the
user.
- Crater fill start level
10 ... 150 %, step 1
Default = 100
- Crater filltime
0.0 ... 10.0 s, step 0.1
Default = 1.0 s
- Crater fillend level
10 ... 150 %, step 1
Default = 30
Current
10 ... machine size A, step 1
Default = 50 A
Welding current adjustment. With
WisePenetration+ only.
Fine tuning
Example: -10.0 ... +10.0 V *
Step 0.1 V
Fine tuning of the welding voltage.
* The voltage range for fine tuning is
defined by the active welding program.
Wise feature
None, WiseFusion, WisePenetration+,
WiseSteel
When selected, a list of available Wise fea-
tures is opened for selection.
Wire feed speed limit min
Min/Max = 0.5 ... 25 m/min, step 0.1
Default = 0.5 m/min
Minimum and maximum limits for the
wire feed speed adjustment.
Wire feed speed limit max
Min/Max = 0.5 ... 25 m/min, step 0.1
Default = 25 m/min
TIG welding parameters
The parameters listed here are available for adjustment with the TIG process.
Parameter Parameter value Description
Trigger logic
2T, 4T Welding guns can have several altern-
ative trigger operation modes (trigger
logics). Most common are 2T and 4T. In
2T mode you hold the trigger down
while welding. In 4T mode you press and
release the trigger to start or to stop weld-
ing.
© Kemppi
87
1920960 / 2144
