MEASure:STRain:{DIRect|FDIRect}? [{<gage_ohms>|MIN|MAX|DEF},
[{<gage_factor>|MIN|MAX| DEF}, [{<range>| MIN|MAX|DEF}, [{<resolution> | MIN | MAX | DEF},]]]]
(@<ch_list>)
DIRect measurements only supported on DAQM901A, DAQM902A, and DAQM908A multiplexer modules.
FDIRect measurements only supported on DAQM901A and DAQM902A multiplexer modules.
Resets all measurement parameters on the specified channels to their default values. Then, configures the channels
for direct 2-wire and 4-wire strain gage measurements and immediately sweeps through the specified channels one
time (independent of the present scan list). The results are sent directly to reading memory and the instrument's out-
put buffer. This command redefines the scan list.
Parameter Typical return
<gage_ohms> = Any numeric value between 80 and 1,100 ohms
Default = 120 ohms
(none)
<gage_factor> = Any numeric value between 0.5 and 5
Default = 2
<range> = {100 Ω | 1kΩ | 10 kΩ | 100 kΩ | 1 MΩ | 10 MΩ | 100 MΩ | 1 GΩ}
Default = 1 kΩ
<resolution> = 1 PLC (0.000003 x Range)
MEASure:STRain:{FULL|HALF}:BENDing? [{<gage_factor> | MIN | MAX | DEF},
[{<range> | MIN | MAX | DEF}, [{<resolution> | MIN | MAX | DEF},]]]] (@<ch_list>)
Only supported on DAQM900A, DAQM901A, DAQM902A, and DAQM908A multiplexer modules.
Resets all measurement parameters on the specified channels to their default values. Then, configures the channels
for full and half bending bridge strain gage measurements and immediately sweeps through the specified channels
one time (independent of the present scan list). The results are sent directly to reading memory and the instrument's
output buffer. This command redefines the scan list.
Parameter Typical return
<gage_factor> = Any numeric value between 0.5 and 5
Default = 2
None
<range> = {Auto | 100 mV | 1V | 10 V | 100V | 300V}
Default = AUTO
<resolution> = 1 PLC (0.000003 x Range)
Keysight DAQ970A/DAQ973A Programming Guide 171
2 SCPI Programming
