Alarm limits Factory reset state
Alarm Output State Output Lines are Cleared
Alarm Output Slope Neg
Module hardware Factory reset state
DAQM900A, DAQM901A, DAQM902A, DAQM908A All Channels Open
DAQM903A, DAQM904A All Channels Open
DAQM905A Channels 11 and 21 Selected
DAQM907A Both DIO Ports = Input, Totalizer Count = 0,Both DACs = 0 VDC/0 A
[1]
DAQM909A All channels' measurement function are off
System-related operations Factory reset state
Display State On (Number)
Error Queue Errors Not Cleared
Stored States No Change
Note:
[1] 0 VDC when output mode is locked to voltage (SOURce:MODE:LOCK OFF command); 0 A when output lock is
locked to current (SOURce:MODE:LOCK ON command).
Keysight DAQ970A/DAQ973A Programming Guide 23
1 Remote Operation
