SOURce:MODE:LOCK {OFF | ON}, (@<ch_list>)
SOURce:MODE:LOCK? (@<ch_list>)
Enables (On) or disables (Off) the locking of the DAC output channel mode (voltage or current). When enabled, the
output mode cannot be changed without disabling the lock.
Only supported on DAQM907A multifunction module (DAC output channels).
Parameter Typical return
{OFF | ON}.
Default: OFF
0 (OFF) or 1 (ON)
Enables locking of the DAC output mode: SOUR:MODE:LOCK ON
– On - Output mode is unlocked.
– Off - Output mode is locked.
– Locking mode stored on the module in non-volatile memory.
– DAC output mode is set to voltage (if it is unlocked with SOUR:MODE:LOCK OFF command). If the output mode
is locked to current with SOUR:MODE:LOCK ON command, an error will be generated.
SOURce:VOLTage {<voltage> | MIN | MAX | DEF}, (@<ch_list>)
SOURce:VOLTage? {(@<ch_list>) | MIN | MAX | DEF}
Sets the output mode in DAC output channels (channel 04 and 05) to voltage.
Only supported on DAQM907A multifunction module (DAC output channels).
Parameter Typical return
<voltage>
MIN: -12 VDC
DEF: 0 VDC
MAX: +12 VDC
+2.5.00000000E+0
Command outputs +2.5VDC on DAC output channels 04 and 05 in slot 2:
SOUR:VOLT 2.5, (@204,205)
OUTP:STAT ON, (@204,205)
– This parameter is set to its default value after a Factory Reset (*RST command).
Keysight DAQ970A/DAQ973A Programming Guide 291
2 SCPI Programming
