TRIGger:DELay {<seconds> | MIN | MAX | DEF}
TRIGger:DELay? [{MIN | MAX | DEF}]
Sets the delay between the trigger signal and the first measurement.
Parameter Typical return
<seconds>
MIN = 0 s
MAX = 3600 s
Default: 0 s
+0.00000000E+00
Set the maximum delay between the trigger signal and the first measurement
TRIG:DEL MAX
– Due to internal quantization, the actual delay that you set may be slightly different than your specified value. The
increment is approximately 1 μs.
– If you have configured the instrument for more than one measurement per trigger (SAMPle:COUNt >1), the
delay is inserted after the trigger and between consecutive measurements.
Keysight DAQ970A/DAQ973A Programming Guide 339
2 SCPI Programming
