TRIGger3:DELay {<seconds> | MIN | MAX | DEF}, (@<ch_list>)
TRIGger3:DELay? {(@<ch_list>) | MIN | MAX | DEF}
Sets the delay between the trigger signal and the first measurement on the specified channels.
These SCPIs are supported on the DAQM909A Digitizer module only.
Parameter Typical return
<seconds>
MIN = 0 s
MAX = 60 s
Default: 0 s
+0.00000000E+00
Set the maximum delay between the trigger signal and the first measurement
TRIG3:DEL MAX,(@201)
TRIGger3:LEVel {<level> | MIN | MAX | DEF}, (@<ch_list>)
TRIGger3:LEVel? [{MIN | MAX | DEF},] (@<ch_list>)
Sets the level on which a trigger occurs when level triggering is selected on the specified channels.
These SCPIs are supported on the DAQM909A Digitizer module only.
Parameter Typical return
<level>
Default: 0
See the table below for the allowable values for each measurement function
+0.00000000E+00
Configures Digitizer channel 201 to perform DC voltage measurement with 1 V range, differential input type, DC coupling, frequency ADC fil-
ter mode, 1024 sample count and 6250 sample rate. Select internal trigger source and set the trigger level to 0.75 volts, positive slope.
ACQ3:VOLT:DC 1,DIFF,DC,FREQ,1024,(@201)
TRIG3:SOUR INT,(@201)
TRIG3:LEV 0.75,(@201)
TRIG3:SLOP POS,(@201)
– The level is specified in the fundamental units for the measurement function. For the DCV function, the allowable
values for the level is dependent on range.
Measurement Function Range <level> parameter values
DCV 0.3 mV to 3 V ±120% of range
18 V ±18 V
Strain All ranges ±0.1 ε (Equivalent to 100,000 microstrain)
346
Keysight DAQ970A/DAQ973A Programming Guide
2 SCPI Programming
