ACQuire?
Returns the channel selected for DMM digitize and its present configurations (channel, function, range, sample
count and sample time).
Parameter Typical return
(none) "VOLT +3.000000E+02,+1.000000E+00,+1.000000E+00,(@101)"
ACQuire:CURRent[:DC] [{<range> | MIN | MAX | DEF}, [{<samp_count> | MIN | MAX | DEF},
[{<samp_time> | MIN | MAX | DEF},]]] (@<channel>)
Configures a single channel for DC current DMM digitizing, but they do not initiate the digitizing. This command
redefines the scan list.
Only supported on DAQM901A's Channel 21 and Channel 22
Parameter Typical return
<range> = { 1μA | 10 μA | 100 μA | 1 mA | 10 mA | 100 mA | 1 A}
MIN: 1 μA
MAX: 1 A
DEF: 1 A
<samp_count>
MIN: 1
MAX: 50,331,648
DEF: 1
<samp_time>
MIN: 20 μs
MAX: 3600 s
DEF: 1 s
(none)
Configures a default current measurement on Channel 121:
ACQ:CURR:DC DEF,DEF,DEF,(@121)
36
Keysight DAQ970A/DAQ973A Programming Guide
2 SCPI Programming
