ACQuire:STRain:QUARter [{<gage_factor> | MIN | MAX | DEF},
[{<excitation_voltage> | MIN | MAX | DEF}, [{<range> | MIN | MAX | DEF},
[{<samp_count> | MIN | MAX | DEF}, [{<samp_time> | MIN | MAX | DEF},]]]]] (@<channel>)
Configures a single channel for quarter bridge strain gage DMM digitizing, but they do not initiate the digitizing.
This command redefines the scan list.
Parameter Typical return
<gage_factor>
MIN: 0.5
MAX: 5
DEF: 2
<excitation voltage>
MIN: 0.9 V
MAX: 12 V
DEF: 5 V
<range> = { 100 mV |1 V | 10 V | 100 V | 300 V }
MIN: 100 mV
MAX: 300 V
DEF: 100 mV
<samp_count>
MIN: 1
MAX: 50,331,648
DEF: 1
<samp_time>
MIN: 20 μs
MAX: 3600 s
DEF: 1 s
(none)
Configures a default quarter bridge strain gage measurement on Channel 101:
ACQ:STR:QUAR DEF,DEF,DEF,DEF,DEF,(@101)
