ACQuire:STRain:{DIRect|FDIRect} [{<gage_ohms> | MIN | MAX | DEF},
[{<gage_factor> | MIN | MAX | DEF}, [{<samp_count> | MIN | MAX | DEF},
[{<samp_time> | MIN | MAX | DEF},]]]] (@<channel>)
Configures a single channel for direct 2-wire or 4-wire strain gage DMM digitizing, but they do not initiate the
digitizing. This command redefines the scan list.
Parameter Typical return
<gage_ohms>
MIN: 80 Ω
MAX: 1.1 kΩ
DEF: 120 Ω
<gage_factor>
MIN: 0.5
MAX: 5
DEF: 2
<samp_count>
MIN: 1
MAX: 50,331,648
DEF: 1
<samp_time>
MIN: 20 μs
MAX: 3600 s
DEF: 1 s
(none)
Configures a default 2-wire strain gage measurement on Channel 101:
ACQ:STR:DIR DEF,DEF,DEF,DEF,(@101)
Keysight DAQ970A/DAQ973A Programming Guide 39
2 SCPI Programming
