ARM3:COUNt {<count> | MIN | MAX | DEF}, (@<ch_list>)
ARM3:COUNt? [{MIN | MAX | DEF},] (@<ch_list>)
Sets the arm count on the specified channels.
These SCPIs are supported on the DAQM909A Digitizer module only.
Parameter Typical return
<count> = an integer specifying the number of arm count
MIN: 1
MAX: Refer to the table below.
Number of DAQM909A installed ARM3:COUNt MAX
1 DAQM909A card installed 87381
2 DAQM909A cards installed 43690
3 DAQM909A cards installed 29127
DEF: 1
+1
Sets the arm count on Digitizer channel 201 to default
ARM3:COUNt DEF,(@201)
– The arm count sets the number of reading records for a channel. The maximum allowed arm count is dependent
on the sample count. Thus, to get maximum number of reading records for a channel, you need to set the
sample count to its minimum. When you increased the sample count, the arm count will be reduced accordingly
by the instrument.
56
Keysight DAQ970A/DAQ973A Programming Guide
2 SCPI Programming
