Keysight Technologies E36100 Series - Specifications and Typical Characteristics

Specifications and Typical Characteristics
Product specifications and descriptions in this document are subject to change without
notice.
Performance Specifications
The following items are the performance specifications of the E36100 Series power supplies.
Tolerance % E36102A E36103A E36104A E36105A E36106A
DC Output Rating (0 to 40 C)
Voltage 6 V 20 V 35 V 60 V 100 V
Current 5.0 A 2.0 A 1.0 A 0.6 V 0.4 A
Load Regulation
± (% of output + offset)
<0.01% + 2 mV 3 mV 6 mV 10 mV 20 mV
<0.02% + 250 μA 100 μA 50 μA 30 μA 20 μA
Line Regulation
± (% of output + offset)
<0.01% + 1 mV 2 mV 4 mV 7 mV 12 mV
<0.02% + 250 μA 100 μA 50 μA 30 μA 20 μA
Ripple and Noise (20 Hz to 20 MHz )
Voltage RMS 350 μV 2 mV 4 mV 5 mV 15 mV
Pk-Pk 10 mV 30 mV 60 mV 100 mV 150 mV
Accuracy 12 Months (23 °C + 5 °C), ± (% output + offset)
Programming
Voltage 0.05% + 3 mV 7 mV 12 mV 20 mV 40 mV
Current 0.05% + 5 mA 1 mA 0.6 mA 0.4 mA 0.3 mA
Readback
Voltage 0.05% + 3 mV 5 mV 8 mV 12 mV 20 mV
Current 0.05% + 4 mA 1 mA 0.5 mA 0.3 mA 0.2 mA
Small Current 0.25% + 40 μA 40 μA 40 μA 40 μA 40 μA
Max. Small Curr. 20 mA 8 mA 4 mA 3 mA 2 mA
Transient Response <50 μs <50 μs <50 μs <50 μs <50 μs
