Safety Symbols
Symbol Meaning
Caution, refer to accompanying documentation.
Protective conductor terminal.
Frame or chassis terminal.
In position of bi-stable push control.
Out position of bi-stable push control.
Alternating current.
Direct current.
Plus, positive polarity.
Minus, negative polarity.
The WARNING sign denotes a hazard. It calls attention to a procedure, practice, or the like, which, if not
correctly performed or adhered to, could result in personal injury. Do not proceed beyond a WARNING sign
until the indicated conditions are fully understood and met.
The CAUTION sign denotes a hazard. It calls attention to an operating procedure, or the like, which, if not
correctly performed or adhered to, could result in damage to or destruction of part or all of the product. Do
not proceed beyond CAUTION sign until the indicated conditions are fully understood and met.
The NOTE sign denotes important information. It calls attention to a procedure, practice, condition or the like,
which is essential to highlight.
