Keysight Technologies E36100 Series User Manual

Test Description Instrument settings
Voltage Programming & Readback, Zero Voltage (V
0
) 0 V 2 A
Voltage Programming & Readback, Maximum Voltage (V
max
) 20 V 2 A
CV Load Regulation, Line Regulation, Ripple and Noise 20 V 2 A
Transient Response 20 V 1 Ato 2 A
Current Programming & Readback, Zero Current (I
0
) 0 A 20 V
Current Programming & Readback, Maximum Current (I
max
) 2 A 20 V
CC Load Regulation, Line Regulation, Ripple and Noise 2 A 20 V
Keysight E36104A
Report number: ______________________
Date: _______________________________
Description Lower limit Result Upper limit
Constant Voltage Tests
Voltage Programming
– Zero Voltage Output (V
0
)
-0.012 V ______________ 0.012 V
– Maximum Voltage Ouput (V
max
)
34.9705 V ______________ 35.0295 V
Voltage Readback
– Zero Voltage measured over interface
V
0
- 0.008 V ______________ V
0
+ 0.008 V
– Maximum Voltage measured over interface
V
max
- 0.0255 V ______________ V
max
+ 0.0255 V
CV Load Regulation (V
load
- V
noload
) -9.5 mV ______________ 9.5 mV
CV Line Regulation (V
lowline
- V
highline
) -7.5 mV ______________ 7.5 mV
CV Ripple and Noise
– peak-to-peak
— ______________ 60 mV
– rms
— ______________ 4 mV
Transient Response — ______________ 50 μs
Constant Current Tests
Current Programming
– Zero Current Output (I
0
)
-0.0006 A ______________ 0.0006 A
– Maximum Current Ouput (I
max
)
0.9989 A ______________ 1.0011 A
Current Readback

Keysight Technologies E36100 Series Specifications

General

Brand	Keysight Technologies
Model	E36100 Series
Category	Power Supply
Language	English
