Keysight Technologies E36100 Series User Manual

Test Description Instrument settings
CV Load Regulation, Line Regulation, Ripple and Noise 6 V 5 A
Transient Response 6 V 2.5 Ato 5 A
Current Programming & Readback, Zero Current (I
0
) 0 A 6 V
Current Programming & Readback, Maximum Current (I
max
) 5 A 6 V
CC Load Regulation, Line Regulation, Ripple and Noise 5 A 6 V
Keysight E36103A
Report number: ______________________
Date: _______________________________
Description Lower limit Result Upper limit
Constant Voltage Tests
Voltage Programming
– Zero Voltage Output (V
0
)
-0.007 V ______________ 0.007 V
– Maximum Voltage Ouput (V
max
)
19.983 V ______________ 20.017 V
Voltage Readback
– Zero Voltage measured over interface
V
0
- 0.005 V ______________ V
0
+ 0.005 V
– Maximum Voltage measured over interface
V
max
- 0.015 V ______________ V
max
+ 0.015 V
CV Load Regulation (V
load
- V
noload
) -5 mV ______________ 5 mV
CV Line Regulation (V
lowline
- V
highline
) -4 mV ______________ 4 mV
CV Ripple and Noise
– peak-to-peak
— ______________ 30 mV
– rms
— ______________ 2 mV
Transient Response — ______________ 50 μs
Constant Current Tests
Current Programming
– Zero Current Output (I
0
)
-0.001 A ______________ 0.001 A
– Maximum Current Ouput (I
max
)
1.998 A ______________ 2.002 A
Current Readback
– Zero Current measured over interface
I
0
- 0.001 A ______________ I
0
+ 0.001 A
– Maximum Current measured over interface
I
max
- 0.002 A ______________ I
max
+ 0.002 A
CC Load Regulation (I
load
- I
short
) -500 μA ______________ 500 μA
CC Line Regulation (I
lowline
- I
highline
) -500 μA ______________ 500 μA
