Description Lower limit Result Upper limit
– Zero Current measured over interface
I
0
- 0.0005 A ______________ I
0
+ 0.0005 A
– Maximum Current measured over interface
I
max
- 0.001 A ______________ I
max
+ 0.001 A
CC Load Regulation (I
load
- I
short
) -250 μA ______________ 250 μA
CC Line Regulation (I
lowline
- I
highline
) -250 μA ______________ 250 μA
Test Description Instrument settings
Voltage Programming & Readback, Zero Voltage (V
0
) 0 V 1 A
Voltage Programming & Readback, Maximum Voltage (V
max
) 35 V 1 A
CV Load Regulation, Line Regulation, Ripple and Noise 35 V 1 A
Transient Response 35 V 0.5 Ato 1 A
Current Programming & Readback, Zero Current (I
0
) 0 A 35 V
Current Programming & Readback, Maximum Current (I
max
) 1 A 35 V
CC Load Regulation, Line Regulation, Ripple and Noise 1 A 35 V
Keysight E36105A
Report number: ______________________
Date: _______________________________
Description Lower limit Result Upper limit
Constant Voltage Tests
Voltage Programming
– Zero Voltage Output (V
0
)
-0.02 V ______________ 0.02 V
– Maximum Voltage Ouput (V
max
)
59.95 V ______________ 60.05 V
Voltage Readback
– Zero Voltage measured over interface
V
0
- 0.012 V ______________ V
0
+ 0.012 V
– Maximum Voltage measured over interface
V
max
- 0.042 V ______________ V
max
+ 0.042 V
CV Load Regulation (V
load
- V
noload
) -16 mV ______________ 16 mV
CV Line Regulation (V
lowline
- V
highline
) -13 mV ______________ 13 mV
CV Ripple and Noise
– peak-to-peak
— ______________ 100 mV
– rms
— ______________ 5 mV
Transient Response — ______________ 50 μs
