Keysight Technologies E36100 Series User Manual

Description Lower limit Result Upper limit
Constant Current Tests
Current Programming
– Zero Current Output (I
0
)
-0.0004 A ______________ 0.0004 A
– Maximum Current Ouput (I
max
)
0.5993 A ______________ 0.6007 A
Current Readback
– Zero Current measured over interface
I
0
- 0.0003 A ______________ I
0
+ 0.0003 A
– Maximum Current measured over interface
I
max
- 0.0006 A ______________ I
max
+ 0.0006 A
CC Load Regulation (I
load
- I
short
) -150 μA ______________ 150 μA
CC Line Regulation (I
lowline
- I
highline
) -150 μA ______________ 150 μA
Test Description Instrument settings
Voltage Programming & Readback, Zero Voltage (V
0
) 0 V 0.6 A
Voltage Programming & Readback, Maximum Voltage (V
max
) 60 V 0.6 A
CV Load Regulation, Line Regulation, Ripple and Noise 60 V 0.6 A
Transient Response 60 V 0.3 Ato 0.6 A
Current Programming & Readback, Zero Current (I
0
) 0 A 60 V
Current Programming & Readback, Maximum Current (I
max
) 0.6 A 60 V
CC Load Regulation, Line Regulation, Ripple and Noise 0.6 A 60 V
Keysight E36106A
Report number: ______________________
Date: _______________________________
Description Lower limit Result Upper limit
Constant Voltage Tests
Voltage Programming
– Zero Voltage Output (V
0
)
-0.04 V ______________ 0.04 V
– Maximum Voltage Ouput (V
max
)
99.91 V ______________ 100.09 V
Voltage Readback
– Zero Voltage measured over interface
V
0
- 0.02 V ______________ V
0
+ 0.02 V
– Maximum Voltage measured over interface
V
max
- 0.07 V ______________ V
max
+ 0.07 V
CV Load Regulation (V
load
- V
noload
) -30 mV ______________ 30 mV
