122 Keysight NFA Series Noise Figure Analyzers Service Guide
Instrument Messages
Condition Messages
Condition Errors 301 to 399, Uncalibrated Integrity
This series of errors corresponds to the bits in the
STATus:QUEStionable:INTegrity:UNCalibrated sub-register. The
second column in the table shows the corresponding bit in that register.
217 7 Demod Error;No
full subframe
found
E No sub-frame or only part of one sub-frame is detected.
217 7 Demod Error;Muxed
bits not found
E Multiplexed Data Demod Bits are not generated even
though Data channel is selected, because all 16 data
code channels are not active
217 7 Demod Error;Acq
Time too short
EFor Bluetooth, the detected packet type doesn’t
match the captured packet type because the payload
start, end or data could not be found.
219 8 Signal Too Noisy E NADC & PDC: The valid EVM measurement cannot be
performed, because the input signal is too noisy.
GSM & EDGE: In a GSM measurement, indicates that a
burst could not be found in a signal that appears noisy.
In PSA, this error was reported as one of the following
error numbers: 10702, 10824, 10906, 10930, 13024,
10626, 111
221 9 Slot Error E
221 9 Slot error;No
active slot found
E No valid active slot found in captured data, or no active
slot found in captured interval. Synchronization may
succeed and pilot found when this message is issued,
but no results are included in peak/average calculation.
221 9 Slot Error; No
idle slot found
E No valid idle slot found in captured data, or no idle slot
found in captured interval. Synchronization may
succeed and pilot found when this message is issued,
but no results are included in peak/average calculation.
223 10 unused E
225 11 unused E
227 12 unused E
229 13 unused E
231 14 unused E
Err# Bit in
status
register
Message Error or
Warning
More Information
