Keysight NFA Series Noise Figure Analyzers Service Guide 25
Overview
Service Equipment You Will Need
Required Test Equipment List
The following table identifies the equipment recommended for
troubleshooting, adjusting, and verifying the performance of the instrument.
Only the recommended and alternate equipment is compatible with the
performance verification testing. Some tests can use various models of a
particular equipment type. The “Recommended Keysight Model” is the
preferred equipment. However, the “Alternative Keysight Model” is an
acceptable substitute.
Table 1-1 Required Test Equipment
Instrument Critical Specifications Recommended
Model
a
Alternative
Model
Use
b
Signal Sources
Microwave Signal
Generator #1
Frequency: 10 MHz to 50 GHz
Frequency Resolution: 1 Hz
Harmonic level: <−30 dBc
Amplitude range: −40 dBm to +13
Amplitude resolution: 0.02
VSWR:
< 20 GHz: 1.6:1
≤ 31 GHz: 1.8:1
E8257D
(Option 567,
1EA/1EU, 1E1)
(Option 007,
Analog Ramp
Sweep, required
for Frequency
Response
Adjustments)
For Adjustments:
83630A/B/L
(Option 001, 008),
83640A/B/L
(Option 001, 008),
83650A/B/L
(Option 001, 008),
PSG
c
A, P, T
Microwave Signal
Generator #2
(only required for Third
Order Intermodulation and
Gain Compression)
Frequency: 10 MHz to 26.5 GHz
Frequency Resolution: 1 Hz
Harmonic level: <−30 dBc
Amplitude range: −20 dBm to +13
Amplitude resolution: 0.02
VSWR:
< 20 GHz: 1.6:1
≤ 31 GHz: 1.8:1
E8257D
(Option
1EA/1EU)
83630A/B
(Option 008),
83640A/B
(Option 008),
83650A/B
(Option 008)
PSG
c
P
Low Noise
Signal Generator
(one PSG may be used for
multiple sources.
See footnote
c
)
Frequency: 50 MHz to 1.0 GHz
Harmonics: < −30 dBc ≤ +13 dBm
Spectral Purity SSB Phase Noise @ 1 GHz:
−112 dBc at 100 Hz offset
−121 dBc at 1 kHz offset
−131 dBc at 10 kHz offset
VSWR: < 1.5:1
E8257D
(Options UNR,
UNX, or UNY)
8663A
PSG
c
(Options UNR,
UNX, or UNY)
A, P, T
