Keysight NFA Series Noise Figure Analyzers Service Guide 391
Assembly Replacement Procedures
Tools you will need
Tools you will need
Figure 15-1 TORX Tool
Adjustments Tests after an instrument repair
Refer to Table 16-1 on page 473 for information about post-repair procedures.
If one or more instrument assemblies have been repaired or replaced, perform
the related adjustments and performance verification tests.
Table 15-1
Description Keysight Part Number
TORX Hand Driver - Size T-10 8710-1623
TORX Hand Driver - Size T-20 8710-1615
9/16 inch nut driver 8720-0008
5/16 inch open-end wrench source locally
cable puller 5021-6773
