Keysight NFA Series Noise Figure Analyzers Service Guide 33
Overview
Service Equipment You Will Need
3.5 mm (f) to 3.5 mm (f)
(for 3.5 mm source)
Frequency: DC to 26.5 GHz
VSWR: ≤ 1.05:1
83059B 1250-1749 P
3.5 mm (m) to 3.5 mm (m)
(2 Required)
Frequency: DC to 26.5 GHz
VSWR: ≤ 1.12:1
83059A 1250-1748 P
3.5 mm (f) to 2.4 mm (f)
(for 2.4 mm source)
Frequency: DC to 26.5 GHz
VSWR: ≤ 1.05:1
11901B P
Type-N (f) to 2.4 mm (f)
(for 2.4 mm source)
Frequency: DC to 18 GHz
VSWR: ≤ 1.08:1
11903B P
Type-N (f) to 2.4 mm (f)
(for 2.4 mm source)
Frequency: DC to 18 GHz
VSWR: ≤ 1.08:1
11903D P
BNC (m) to SMA(f) Frequency: DC to 1.3 GHz
VSWR: ≤ 1.13:1
1250-1700 P
BNC Tee (BNC f,m,f) 1250-0781 A, P
SMB (f) to BNC (f) Frequency: DC to 1.3 GHz 1250-1236 A, P
BNC (f) to SMA (m) Frequency: DC to 1.3 GHz 1250-1200 A, P
BNC (f) to Dual Banana 1251-2277 A, P
3.5 mm (f) to Type-N (m) Shipped with the 8485A for adapting to the
Power Reference. Only to be used for power
sensor cal.
08485-60005 A, P
2.4 mm (f) to Type-N (m) Shipped with the 8487A for adapting to the
Power Reference. Only to be used for power
sensor cal.
08487-60001 A, P
Type-N Tee 1250-0559 P
Optional Equipment
10 MHz Distribution
Amplifier
(only needed when using
the 10 MHz Distribution
Amplifier Setup)
Microsemi
5087B
Keysight 5087A
Symmetricom
5087B
A, P
1 GHz Notch Filter
(for alternate Phase Noise
setup)
Center Frequency: 1.0001 GHz Trilithic
CFN-2-1000.1
P
a. Keysight model numbers unless otherwise noted.
b. A = Adjustments, P = Performance Testing, T = Troubleshooting
Table 1-1 Required Test Equipment
Instrument Critical Specifications Recommended
Model
a
Alternative
Model
Use
b
