356 Keysight NFA Series Noise Figure Analyzers Service Guide
Replaceable Parts
Replaceable Parts
A13MP1 Spacer, Bandpass Filter Mounting Adapter
(N8973B, 74B, 75B)
E6607-25005
A14 L.O. Synthesizer Assembly N9020-60118
A15 Front End Control Assembly
Standard on N8973B, 74B, 75B N9020-60098
N8976B N9020-60172
A16 Reference Assembly N9020-60200
B1-B2 Fan 3160-4199
J1 Type-N (f) RF Input Connector Assembly (N8973B, 74B, 75B) 5002-0702
2.4 mm (m) Input Connector Assembly (N8976B) N9030-60011
EMI O-Ring 18.75 mm ID
(used between RF Input Connector and Front Frame)
8160-1637
MP1 Chassis Base N9020-00032
MP2 Chassis Side, Right (inner) W1312-00135
MP3 Chassis Side, Left (inner) W1312-00136
MP4 Midplane Bracket W1312-00048
MP5 Chassis Front Bracket N9020-00059
MP6 Fan Bracket W1312-00137
MP7 Top Brace (includes foam strips) N9020-60018
MP8 Chassis Side, Right (Outer, attaches to Low Band Switch bracket, Attenuator
brackets, and Chassis bottom)
N9020-00034
MP9 Rear Panel Replacement Kit (includes foam strip) N9020-60298
MP10 Reserved
MP11-12 Coax Cable Clips 5041-9690
MP13-15 Tie Wrap (For long semi-rigid cables) 1400-0249
MP16 Dress Cover (includes magnetic gasket and snaps) N9010-00002
MP17-20 Rear Feet (Benchtop Configuration) 5041-7903
MP21-22 Strap Handles (Benchtop Configuration) N9020-60252
MP25-26 Fan Guard 3160-0281
MP27-34 Rivet, Fan Mounting (8 pieces) 0361-1272
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
