Keysight x-series Getting Started And Troubleshooting

2 Front and Rear Panel Features
Front-Panel Features
Item
Description
# Name
6 Enter and Arrow Keys
The Enter key terminates data entry when either no unit of
measure is needed, or you want to use the current unit.
The arrow keys:
– Increment and decrement the value of the current
measurement selection. (up/down = big increment,
left/right = small increment)
– Navigate help topics.
– Navigate or make selections within Windows dialogs.
– Navigate within forms used for setting up measurements.
– Navigate within tables.
7 Knob Increments and decrements the value of the current active
function.
8 Utility Key
The following keys are available in the Utility section:
Numeric key pad
System
Help
Local/Cancel/(Esc)
Back-space
Delete
Control
Alt
Undo/Redo
Touch On/Off
Onscreen Keyboard
Tab
9 Input 1
2.4 mm (m)
Connector for inputting external signals 3 Hz to 50 GHz. Make
sure that the total power of all signals at this analyzer input
does not exceed +30 dBm (1 watt).
10 USB Connectors Standard USB 2.0 ports, Type A. Connect to external
peripherals such as a mouse, keyboard, DVD drive, or hard
drive.
11 Headphones Output Headphones can be used to hear any available audio output.
12 Probe Power Supplies power for external high frequency probes and
accessories.
13 Ext Mixer Provides LO output signal to and receives IF input signals from
an external mixer. See the Specifications Guide for details on
signal levels.
Getting Started and Troubleshooting Guide 21

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
