10
Caster Forks and Stems
Single Sided Fork
1. Install stem (A) into single sided fork (B) with washer (C) and nut (D) using a ½" wrench.
2. Install caster wheel (F) onto fork (B) with a screw (E), the axle shaft (G) and secure with E-Ring (H).
NOTE: There are two sizes of caster stems (standard and +3/4") and two sizes of forks (short and
tall) that can be used. The installation process is the same for whichever stem and fork you use.
A
B
C
D
E
F
G
H
