KI ROGUE 2 - Tools; Frame Tube Size Guide; Spoke Tension Values

3
Tools
Please see the list below to identify the tools needed throughout this tech manual. Always
check tools to ensure the ends are not stripped and that the tool can perform its function
properly without damaging any parts or hardware on the chair.
Frame Tube Size Guide
*Tubing sizes subject to change without notice*
This information is a reference for situations where the tube sizes are needed for certain
attachments.
Spoke Tension Values
Tools Needed
• 2.5mm Allen Wrench • Two 8mm Wrenches • Utility Blade
• 3mm Allen Wrench • Two 10mm Wrenches • Calibrated Torque
Wrench
• 4mm Allen Wrench • 13mm Wrench • Rubber Mallet
• 5mm Allen Wrench • 17mm Wrench • Phillips Screwdriver
• 5.5mm Allen Wrench • 19mm Wrench • Punch (or small
screwdriver)
• 6mm Allen Wrench • 24mm Wrench
Rogue 2 Rogue XP
Frame Tube Frame Tube
Frame Tube: 1 3/8” Frame Tube: 1 3/8”
Camber Tube: 1 1/8” Camber Tube: 1 1/8”
Back Canes Back Canes
Fixed Height Back Canes: 1” Fixed Height Back Canes: 1”
Rigidizer Bar: 7/8” Rigidizer Bar: 7/8”
Lower Height Adjustable Back Tube: 1” Lower Height Adjustable Back Tube: 1”
Upper Adjustable Upper Back Tube: 3/4” Upper Adjustable Upper Back Tube: 3/4”
Half Folding Back: 7/8”
Arms Arms
Swing Away: 1” Swing Away: 1”
Upper T-Arm: 7/8” Upper T-Arm: 7/8”
Transfer Tube T-Arm: 3/4” Transfer Tube T-Arm: 3/4”
Angle Adjustable Flip Up: 1”
Footrests Footrests
Footrest Tubes: 3/4” Footrest Tubes: 3/4”
OAD Spoke 60-100 kgf
Drum brake Spoke 90-120 kgf radial side / 60-90 kgf crossed side
Maxx Spoke 60-100 kgf
Low Cost Spoke 60-100 kgf
Superlight Spoke 92-112 kgf
