37
Seat Pan
NOTE: Remove any current seating or cushions before installing the seat pan.
1. Install the seat pan (B) onto the chair frame and secure with screws (A) using a Phillips screwdriver.
2. If not already done, install the tape onto the seat as shown in the image below. The tape should cover
as much area as possible without hanging over the edge or covering one of the screw holes.
Part Number Tape Size Seat Pan Depth
004458 3" X 4" 10" - 11"
004458 & 004459 3" X 4" & 3" X 5" 12"
004459 3" X 5" 13"
004460 3" X 6"
14" - 22" (19" - 22")
Seat Depth Screw Qty
10" - 12" 6
13" - 15" 8
16" - 18" 10
19" - 21" 12
22" 14
