8
Caster Forks and Stems
Remove Caster Fork and Stem
1. Remove bottom nut and washer using a 17mm or ¾" socket wrench. Remove fork assembly.
NOTE: Based on your configuration, the caster may need to be removed first to allow clearance for
wrench (See step 3).
2. Remove the caster wing covers by removing the M4 bolt with a 2.5mm Allen wrench. Remove the
caster stem by removing the M5 bolt with a 4mm Allen wrench.
Regular Caster Fork
Single Sided Caster Fork
