KI ROGUE 2 - Height Adjustable T-Arm

28
Height Adjustable T-Arm
1. Install the T-Arm receiver (B) and the T-Arm bracket (C) onto frame with two bolts (D) and two nuts (A)
using a 5mm Allen wrench and a 10mm wrench.
2. Install the T-Arm assembly into the receiver. Ensure the latch (B) "clicks" into place. Adjust the height by
loosening the height lever (A) and sliding the T-Arm post up or down. Repeat steps on opposite side.
A
B
C
D
A
B
