KI ROGUE 2 - Bolt-On Push Handle - Rogue XP

26
Bolt-On Push Handle - Rogue XP
1. Install the clamps (B & C) and bolt-on push handle tube (E) onto the rigidizer bar and secure with two
screws (A) and two nuts (D) using a 5mm Allen wrench.
NOTE: The clamps can be installed onto the rigidizer bar in the straight or angled orientation. See
image below for details.
2. Repeat installation step with the second bolt-on push handle.
Straight
Angled
Straight
Angled
A
B
C
D
E
