Features of your vehicle Instrument cluster
Red zone
Do not operate the engine within the
tachometer's RED ZONE. This may cause
severe engine damage.
Engine coolant temperature
gauge
This gauge indicates the temperature of
the engine coolant when the ENGINE
START/STOP button is ON.
If the gauge pointer moves beyond the
normal range area (between the C-H)
toward the "H" position, it indicates over
-
heating that may damage the engine.
Do not continue driving with an over
-
heated engine. If your vehicle overheats,
refer to "If the engine overheats" on
page 7-6.
Never remove the engine coolant reser
-
voir cap when the engine is hot. The
engine coolant is under pressure and
could severely burn. Wait until the
engine is cool before adding coolant to
the reservoir.
Engine coolant reservoir cap
Do not remove the engine cool
-
ant reservoir cap when the
engine is hot. This may result in
coolant being blown out of the
opening and cause serious burns.
Fuel gauge
This gauge indicates the approximate
amount of fuel remaining in the fuel
tank.
僅 The fuel tank capacity is given in
"Recommended lubricants and capac
-
ities" on page 9-9.
僅 The fuel gauge is supplemented by a
low fuel warning light, which will
appear when the fuel tank is nearly
empty.
僅 On inclines or curves, the fuel gauge
pointer may fluctuate or the low fuel
warning light may come on earlier
than usual due to the movement of
fuel in the tank.
ODL3049103
ODL3042104
