Maintenance
508
Fuses
Replacing engine compartment
fuse
1. Turn the ENGINE START/STOP button
and all other switches off.
2. Remove the fuse panel cover by
pressing the tab and pulling the cover
up.
3. Check the removed fuse; replace it if
it is blown. To remove or insert the
fuse, use the fuse puller in the engine
compartment fuse panel.
4. Push in a new fuse of the same rating,
and make sure it fits tightly in the
clips. If it fits loosely, consult an autho
-
rized Kia dealer.
Always securely install the fuse panel
cover in the engine compartment to pro
-
tect against electrical failure which may
occur from water contact. Listen for the
audible clicking sound to ensure fuse
panel cover is securely fastened.
If the main (multi) fuse is blown, have
the vehicle checked by an authorized Kia
dealer.
The electronic system may not function
correctly even when the engine com
-
partment and internal fuse box's individ
-
ual fuses are not disconnected. In such
cases, the cause of the problem may be
disconnection of the main fuse (BFT
type), which is located inside the positive
battery terminal (+) cap. Since the main
fuse is designed more intricately than
other parts, have the vehicle checked by
an authorized Kia dealer.
After checking the fuse panel in the
engine compartment, securely install the
fuse panel cover through the audible
clicking sound. If not, electrical failures
may occur from water contact.
Main fuse (Multi fuse)
If the multi fuse is blown, it must be
removed as follows:
1. Turn the ENGINE START/STOP button
and all other switches off.
2. Disconnect the negative battery cable.
3. Remove the nuts shown in the picture
above.
4. Replace the fuse with a new one of
the same rating.
5. Reverse these steps to reinstall the
multi fuse.
