Maintenance Light bulbs
Replacing front side marker lamp
bulb (LED type)
If the front side marker lamp LED (1)
does not operate, have the vehicle
checked by an authorized Kia dealer.
Replacing side repeater lamp
bulb (LED type) (if equipped)
If the side repeater lamp LED (1) does
not operate, have the vehicle checked
by an authorized Kia dealer.
Replacing rear tail & stop lamp,
stop lamp, turn signal lamp, back
up lamp bulb (Bulb type)
Type A
Type B
1. Tail and stop lamp
2. Tail lamp (center)
3. Turn signal lamp
4. Back up lamp
To replace the bulb:
1. Engage the parking brake, shift to P
and turn the ignition OFF.
2. Turn of the rear combination lamp.
3. Open the trunk.
4. Remove the rear combination lamp
assembly or rear trunk trim from the
ODL3079048L
ODL3079049
