Maintenance Fuses
trailers etc., the inner junction block
can get burned.
Electrical wiring repairs
All electrical repairs should be per
-
formed by authorized Kia dealerships
using approved Kia parts. Using other
wiring components, especially when ret
-
rofitting multimedia or theft alarm sys
-
tem, car phone or radio may cause
vehicle damage and increase the risk of
a vehicle fire.
Remodeling Prohibited
Do not rewire your vehicle in any way as
doing so may affect the performance of
several safety features in your vehicle.
Rewiring your vehicle may also void your
warranty and cause you to be responsi
-
ble for any subsequent vehicle damage
which may result.
Replacing inner panel fuse
1. Turn the ENGINE START/STOP button
and all other switches off.
2. Open the fuse panel cover.
3. Pull the suspected fuse straight out.
Use the removal tool provided on the
engine fuse panel cover.
4. Check the removed fuse; replace it if
it is blown.
Spare fuses are provided in the
engine compartment fuse panel.
5. Push in a new fuse of the same rating,
and make sure it fits tightly in the
clips.
If it fits loosely, consult an authorized Kia
dealer.
If you do not have a spare, use a fuse of
the same rating from a circuit you may
not need for operating the vehicle, such
as the power outlet fuse.
If the head lamp, turn signal lamp, stop
signal lamp, fog lamp, DRL, tail lamp,
High Mounted Stop Lamp (HMSL) do not
work and the fuses are OK, check the
fuse panel in the engine compartment. If
a fuse is blown, it must be replaced.
If the headlamp, fog lamp, turn signal
lamp, or tail lamp malfunction even with
-
out any problem to the lamps, have the
vehicle checked by an authorized Kia
dealer for assistance.
