Safety features of your vehicle
123
Seat
Type B
To remove the headrest:
1. Recline the seatback (2) with the
recline lever or switch (1).
2. Raise headrest as far as it can go.
3. Press the headrest release button (3)
while pulling the headrest up (4).
Removing headrest
NEVER allow anyone to ride in a seat
with the headrest removed or reversed.
Headrests can provide critical neck and
head support in a crash.
Reinstalling headrest
Type A
Type B
To reinstall the headrest:
1. Put the headrest poles (2) into the
holes while pressing the release but
-
ton (1).
2. Recline the seatback (4) with the
recline lever or switch (3).
3. Adjust the headrest to the appropriate
height.
Headrest reinstallation
To reduce the risk of injury to the head
or neck, always make sure the headrest
is locked into position and adjusted
properly after reinstalling.
ODL3A030012
ODL3A030013
ODL3A030014
