Maintenance Fuses
PCB Block: Smartstream G2.5 T-GDi
SENSOR1 15A Oxygen Sensor (Up/Down)
OIL PUMP2 10A Electronic Oil Pump
CVVD2 10A CVVD Actuator
POWER OUTLET2 20A Front Power Outlet Left Handle side
POWER OUTLET3 20A Front USB Charger
HORN 20A PCB Block (Horn Relay)
SENSOR2 10A
Oil Control Valve (Intake/Exhaust), Variable Oil Pump Solenoid Valve,
Purge Control Solenoid Valve, RCV (Recirculation Valve Control)
Control Solenoid Valve, Canister Close Valve, Engine Room Junction
Block (Air Conditioner Relay)
FUEL PUMP2 10A Engine Room Junction Block (Fuel Pump Relay)
ECU3 10A ECM (Engine Control Module)
ABS3 10A ESC (Electronic Stability Control) Module
IGN COIL 20A Ignition Coil #1 ~ #4
CRUISE 10A Front Radar
Fuse Name Fuse rating Circuit Protected
Fuse Name Fuse rating Circuit Protected
WIPER1 30A PCB Block (Wiper Relay)
WIPER2 10A IBU (Integrated Body Control Unit), ECM (Engine Control Module)
TCU1 20A Not Used
ECU2 15A ECM (Engine Control Module)
ECU1 20A ECM (Engine Control Module)
ECU4 15A ECM (Engine Control Module)
TCU2 15A TCM (Transmission Control Module)
A/C1 10A Engine Room Junction Block (Air Conditioner Relay)
INJECTOR 15A Injector #1 ~ #4
SENSOR1 15A Oxygen Sensor (Up/Down)
POWER OUTLET2 20A Front Power Outlet Left Handle side
POWER OUTLET3 20A Front USB Charger
HORN 20A PCB Block (Horn Relay)
SENSOR2 10A
Oil Control Valve (Exhaust), Variable Oil Pump Solenoid Valve, Purge
Control Solenoid Valve, RCV (Recirculation Valve Control) Control
Solenoid Valve, Canister Close Valve, Engine Room Junction Block
(Air Conditioner Relay)
FUEL PUMP2 10A Engine Room Junction Block (Fuel Pump Relay)
ECU3 10A ECM (Engine Control Module)
ABS3 10A ESC (Electronic Stability Control) Module
IGN COIL 20A Ignition Coil #1 ~ #4
CRUISE 10A Front Radar
