A-18 Appendix PLZ-U
Configuration and operation commands
SCPI Command Description Query Note 1 Note 2
[SOURce:]FUNCtion
[:MODE] {CC|CV|CR|CCCV|CRCV} Sets the operation mode of the PLZ-U.
Yes 3
:SSTart
{0.1MS|1MS|3MS|10MS|30MS|100MS|
300MS|MINimum|MAXimum}
Sets soft start in CC mode..
Yes 3
[SOURce:]CONDuctance
[:LEVel][:IMMediate]
[:AMPLitude] {<conduc-
tance>|MINimum|MAXimum}
Sets the conductance of CR mode.
Yes 3
:RANGe {LOW|MEDium|HIGH} Sets the range of CR mode.
Yes 3
[SOURce]:CURRent
[:LEVel][:IMMediate][:AMPLi-
tude]{<current>|MINimum|MAXi-
mum}
Sets the current value.
Yes 1
:SLEW <slew> Sets the amount of current change per unit time.
Yes 1
:PROTection[:LEVel][:OVER]
{<value>|MINimum|MAXimum}
Sets the overcurrent protection level.
Yes 1
:PROTection:ACTion {LIMit|TRIP} Sets whether to turn off the load or limit the cur-
rent when the OCP trips.
Yes 3
:RANGe {LOW|MEDium|HIGH} Sets the range of CC mode.
Yes 1
[SOURce]:POWer
:PROTection[:LEVel][:OVER]
{<value>|MINimum|MAXimum}
Sets the overpower protection level.
Yes 1
:PROTection:ACTion {LIMit|TRIP} Sets whether to turn off the load or limit the cur-
rent when the OPP trips.
Yes 3
[SOURce:]VOLTage
[:LEVel][:IMMediate][:AMPLi-
tude][:AMPLitude] {<volt-
age>|MINimum|MAXimum}
Sets the voltage value.
Yes 1
:PROTection[:LEVel]UNDer
{<voltage>|MINimum|MAXimum}
Sets the overvoltage protection level.
Yes 3
:PROTection:STATe {OFF|ON} Turns ON/OFF the undervoltage protection.
Yes 1
:RANGe {LOW|HIGH} Sets the range of CV mode.
Yes 1
[SOURce:]PRESet
:STORe {MEMA|MEMB|MEMC} Stores the settings to ABC preset memory. N/A 3
:RECall {MEMA|MEMB|MEMC} Recalls settings from ABC preset memory. N/A 3
DISPlay:METer {0|1|2|3|4} Turns ON/OFF the elapsed time.
Yes 3
HCONfigration:POLoad {OFF|ON}
Sets whether to power up with the load turned on.
Yes 3
