PLZ-U Appendix A-19
Trigger commands
Switching function commands
Input state commands
SCPI Command Description Query Note 1 Note 2
ABORt Clears the trigger-wait status and returns to idle. N/A 1
INPut[:STATe]:TRIGgered {OFF|ON} Turns the load on/off using trigger input. N/A 1
OUTPut[:STATe]:TRIGgered {OFF|ON} Turns ON/OFF the trigger input. N/A 1
INITiate
[:IMMediate] Transitions to the trigger wait status, but automati-
cally returns to idle when a trigger is activated.
N/A 1
:CONTinuous {OFF|ON} Sets whether to continue the trigger wait status.
Yes 1
[SOURce:]
CONDuctance[:LEVel]:TRIG-
gered[:AMPLitude] {<conduc-
tance>|MINimum|MAXimum}
Sets the conductance generated when a trigger is
activated.
N/A 3
CURRent[:LEVel]:TRIG-
gered[:AMPLitude] {<cur-
rent>|MINimum|MAXimum}
Sets the current when a trigger is activated.
N/A 1
SCPI Command Description Query Note 1 Note 2
[SOURce:]PULSe
[:STATe] {OFF|ON} Turns on/off the switching mode.
Yes 3
:DCYCle <value> Sets the switching duty cycle.
Yes 1
:FREQuency <value> Sets the pulse frequency.
Yes 3
[SOURce:]PULSe:LEVel
[:VALue]:CONDuctance <conduc-
tance>
Sets the level for CR mode.
Yes 3
[:VALue]:CURRent <current> Sets the level for CC mode.
Yes 3
SCPI Command Description Query Note 1 Note 2
INPut/OUTPut
[:STATe][:IMMediate] {OFF|ON} Turn ON/OFF the load.
Yes 1
:EXTernal:LPOLarity |POSi-
tive|NEGative}
Sets the polarity of the channel control signal.
Yes 3
:EXTernal:REFerence
{NONE|MAIN|SUB}
Sets the external analog control of the load unit.
Yes 3
:PROTection:CLEar Clears the alarm. N/A 3
[:STATe]:TIMer[:STATe]
{<value>|MINimum|MAXimum}
Sets the cutoff time.
Yes 3
[:STATe]:DELay: {<value>|MINi-
mum|MAXimum}
Sets the delay time until the load is turned on.
Yes 1
