KINTECH ENGINEERING
ORBIT 360 | USER GUIDE
40
14
5
Sensor signal
Input channel 5 (freq. / pulses)
15
5V
5V DC supply
Continuous power supply for Thies FC,
K611P, K620A…
16
-
Sensor GND
Sensor supply(-) / signal reference
17
6
Sensor signal
Input channel 6 (freq. / pulses)
18
5V
5V DC supply
Continuous power supply for Thies FC,
K611P, K620A…
19
-
Sensor GND
Sensor supply(-) / signal reference
20
7
Sensor signal
Input channel 7 (freq. / pulses)
21
5V
5V DC supply
Continuous power supply for Thies FC,
K611P, K620A…
22
-
Sensor GND
Sensor supply(-) / signal reference
23
8
Sensor signal
Input channel 8 (freq. / pulses)
24
5V
5V DC supply
Continuous power supply for Thies FC,
K611P, K620A…
25
-
Sensor GND
Sensor supply(-) / signal reference
26
9
Sensor signal
Input channel 9 (freq. / pulses)
27
5V
5V DC supply
Continuous power supply for Thies FC,
K611P, K620A…
28
-
Sensor GND
Sensor supply(-) / signal reference
29
10
Sensor signal
Input channel 10 (freq. / pulses)
30
5V
5V DC supply
Continuous power supply for Thies FC,
K611P, K620A…
31
A
Modbus RTU
RS485 data +
32
B
Modbus RTU
RS485 data -
33
A1
RS485 Bus 1
Data +
