KINTECH ENGINEERING
ORBIT 360 | USER GUIDE
41
34
B1
RS485 Bus 1
Data -
35
-
Supply(-)
Power supply GND
36
+
Supply(+)
Battery(+) with current limitation (200
mA)
37
A2
RS485 Bus 2
Data +
38
B2
RS485 Bus 2
Data -
39
-
Supply(-)
Power supply GND
40
+
Supply(+)
Battery(+) with current limitation (200
mA)
41
A3
RS485 Bus 3
Data +
42
B3
RS485 Bus 3
Data -
43
RX
Received serial data
RS-232 to interface with external modem
44
TX
Transmitted serial
data
RS-232 to interface with external modem
45
-
Supply(-)
Power supply GND
46
+
Supply(+)
Battery(+) with current limitation (12 mA)
47
-
Sensor GND
Sensor supply(-) / signal reference
48
1
Sensor signal
Input channel 1 (voltage)
49
+
Supply(+)
Battery(+) with current limitation (12 mA)
50
5
5V discontinuous
supply
Discontinuous power supply for
potentiometric wind vanes, K307T…
51
-
Sensor GND
Sensor supply(-) / signal reference
52
2
Sensor signal
Input channel 2 (voltage)
53
+
Supply(+)
Battery(+) with current limitation (12mA)
54
5
5V discontinuous
supply
Discontinuous power supply for
potentiometric wind vanes, K307T…
