42
55
-
Sensor GND
Sensor supply(-) / signal reference
56
3
Sensor signal
Input channel 3 (voltage)
57
+
Supply(+)
Battery(+) with current limitation (12mA)
58
5
5V discontinuous
supply
Discontinuous power supply for
potentiometric wind vanes, K307T…
59
-
Sensor GND
Sensor supply(-) / signal reference
60
4
Sensor signal
Input channel 4 (voltage)
61
+
Supply(+)
Battery(+) with current limitation (12mA)
62
5
5V discontinuous
supply
Discontinuous power supply for
potentiometric wind vanes, K307T…
63
2V5
2.5V DC
Continuous power supply for Davis
pyranometer, propeller anemometer…
64
-
Sensor GND
Sensor supply(-) / signal reference
65
5
Sensor signal
Input channel 5 (voltage)
66
+
Supply(+)
Battery(+) with current limitation (12mA)
67
o1
Alarm output #1
Battery(+) with current limitation (2000
mA)
Discontinuous
supply(+)
Discontinuous battery(+) with current
limitation (2000 mA) for Setra barometer
68
-
Sensor GND
Sensor supply(-) / signal reference
69
6
Sensor signal
Input channel 6 (voltage)
70
+
Supply(+)
Battery(+) with current limitation (12mA)
71
o2
Alarm output #2
Battery(+) with current limitation (2000
mA)
Discontinuous
supply(+)
Discontinuous battery(+) with current
limitation (2000 mA) for Setra barometer
