43
72
-
Sensor GND
Sensor supply(-) / signal reference
73
7
Sensor signal
Input channel 7 (voltage)
74
+
Supply(+)
Battery(+) with current limitation (12mA)
75
o3
Alarm output #3
Battery(+) with current limitation (2000
mA)
Discontinuous
supply(+)
Discontinuous battery(+) with current
limitation (2000 mA) for Setra barometer
76
-
Sensor GND
Sensor supply(-) / signal reference
77
8
Sensor signal
Input channel 8 (voltage)
78
+
Supply(+)
Battery(+) with current limitation (12mA)
79
o4
Alarm output #4
Battery(+) with current limitation (2000
mA)
Discontinuous
supply(+)
Discontinuous battery(+) with current
limitation (2000 mA) for Setra barometer
80
-
Sensor GND
Sensor supply(-) / signal reference
81
9
Sensor signal
Input channel 9 (voltage)
82
+
Supply(+)
Battery(+) with current limitation (12mA)
83
o5
Alarm output #5
Battery(+) with current limitation (2000
mA)
Discontinuous
supply(+)
Discontinuous battery(+) with current
limitation (2000 mA) for Setra barometer
84
10
Sensor signal
Input channel 10 (voltage)
85
11
Sensor signal
Input channel 11 (voltage)
86
12
Sensor signal
Input channel 12 (voltage)
87
-
Sensor GND
Sensor supply(-) / signal reference
88
+
Supply(+)
Battery(+) with current limitation (12mA)
