Kinze 4900 - LUBRICATION AND MAINTENANCE; Hydraulic Schematic (Hydraulic Drive Option)

TM
Model 4900M0290-01
Rev. 8/19 6-113
Lubrication and Maintenance
HYDRAULIC SCHEMATIC (HYDRAULIC DRIVE OPTION)
Return (A2)
Return (E1)
Pressure (F1)
Hoses are included
with base machine
Pressure
(A3)
Seed Rate
Cable
Pressure (F2)
Return (D1)
/" Hose = Pressure
" Hose = Return
