M0290-01Model 4900
TM
Row Unit Operation
3-6 Rev. 8/19
FIELD OPERATION
NOTE: Adjust down pressure with planter lowered and row openers in ground for most accurate adjustment.
Pressure can be adjusted using your Blue Vantage monitor. Refer to the Blue Vantage manual for more
information.
ADJUST DOWN PRESSURE FROM CAB
For models equipped with an Blue Vantage monitor, use the monitor to adjust down pressure. Refer to your Blue
Vantage manual for more information.
For models equipped with a control box, toggle the Down Pressure Switch up or down to increase or decrease down
force.
Refer to M0288 - Kinze Blue Vantage Operator’s Manual for pressure adjustment with Blue Vantage.
Air Compressor
Pressure gauge
FUNCTION
FOLDPLANT
OFF
HITCH
FOLD
OFF
AXLE
WING
WHEELS
DP INCR L INCR
VACUUM
R INCR
DP DECR L DECR
R DECR
WORK
LIGHTS
BF
ONLY
OFF
MARKERS
OFF
RIGHTLEFT
OFF
RIGHT
LEFT
POINT ROW
TM
Control Box
