M0290-01Model 4900
2-16 Rev. 8/19
TM
Machine Operation
TRANSPORT TO FIELD SEQUENCE USING CONTROL BOX
(If applicable, refer to ““Transport to Field Sequence Using Blue Vantage” on page 2-21)
Position planter in a relatively flat open area without furrows, etc.
SUMMARIZED TRANSPORT TO FIELD SEQUENCE
USING CONTROL BOX
The control box and VT (virtual terminal) should not be used at the same time.
Make sure markers are disabled on the VT when the control box is used to
fold/unfold the planter.
1. Remove lockups.
2. Place function switch on control box in FOLD position.
3. If equipped with drawbar hitch, raise hitch slightly and remove
hitch locking pin.
4. Move transport axle into field turnaround position.
5. Lower wing wheels into field turnaround position.
6. Lower hitch to sufficiently clear transport wing hooks.
7. Fold wings outward until stub wing latch pins are sealed into
H-frame receivers.
8. Lower planter and hold hydraulic lever for an additional 30
seconds to rephase lift cylinders.
9. If equipped with row markers, remove lockups and place in storage
position.
10. Lower hitch to level machine during planting.
NOTE: Read following information for detailed instructions.
Tractor must be in neutral and allowed
to roll freely when unfolding to prevent
equipment damage, especially in soft
conditions or when loaded with seed or
fertilizer. Use tractor assist as needed to
aid in unfolding and to reduce stress on
frame and transport components.
NOTICE
