Model 4900M0290-01
Rev. 8/19 2-13
Machine Operation
TRANSPORTING PLANTER
Make sure safety/warning lights, reflective decals, and SMV sign are in place and visible before transporting machine
on public roads. It is your responsibility to check and comply with all federal, state/provincial, and local regulations.
Be aware of road and bridge weight limits. Allow for additional weight of added options and any additional material or
substances that have been added to the machine.
Transporting planter with hoppers over
half full or unevenly loaded can cause
loss of control and could result in death,
serious injury, or damage to property and
equipment. Properly load planter when
transporting. Be aware of extra transport
weight, and road conditions and limits.
WARNING
Uncontrolled movement of equipment
can cause loss of control and could
result in death, serious injury, or damage
to property and equipment. Install
all safety pins before transporting
equipment.
WARNING
Uncontrolled machine movement can
crush or cause loss of control resulting
in death, serious injury, or damage to
property and equipment. Install all safety
lockup devices before working under or
transporting this equipment.
WARNING
To avoid unintended movement of
axle during transport, return all SCV
controls to the neutral position before
transporting machine. DO NOT operate
any hydraulic function while transporting
machine. Doing so could result in death,
serious injury, or damage to property and
equipment.
WARNING
Transport axle can lower from transport
position without the use of any
controller, causing death, serious injury,
or damage to property and equipment.
Do not operate any hydraulic function
while transporting the planter. Make sure
all transport safety lockups are installed
on the four transport cylinders and all
SCV controls are in their neutral state
before transporting, storing and working
on the planter.
WARNING
