4-23
REMOVING THE OVEN DOOR GASKET
REASSEMBLY NOTE: After the door gasket
is installed, make sure that it is even along the
surface of the door when the door is closed.
1. Remove the oven door (see page 4-22 for
the procedure).
2. Remove the screw from the door gasket
cover and remove the cover.
3. Starting at one end of the door gasket, pull
the clips out of the liner holes, and remove
the gasket.
Gasket Cover
Pull Gasket Clips
Out Of Liner Holes
To Next Page
