KKT cBoxX 30 - Elements

11 / 89 83000102.Ki
1.2. Elements
1
Metal cladding, top, operator side
a
Safety instructions
2
Metal cladding, bottom, operator side
b
Water connections
3
Metal cladding, top, service side
c
Rating plate
4
Metal cladding, bottom, service side
d
Display
5
Metal cladding, condenser protective grating
e
Main switch
6
Cladding, hydraulics
1
2
3
4
5
6
a
b
c
d
e
