Section 11
Specifications
20413013
8-2012/Rev 10
11-12
Torque Specifications
7/8 inch (22 mm)
Diameter Plunger
1-1/8 inch (29 mm)
Diameter Plunger
Hydraulic Cylinder Head
Socket Head Screws 8 (14M) each 6 (3/4”) each
Torque 75-80 ft-lbs (102-108 Nm) 170-175 ft-lbs (230-237 Nm)
Hex Key M12 5/8 inch
Proximity Switch
Socket Head Screws 2 (M6) each 2 (1/4”) each
Torque 140-160 in-lbs (16-18 Nm) 140-160 in-lbs (16-18 Nm)
Hex Key M5 3/16 inch
Topworks Support
Socket Head Screws 4 (M10) each 4 (3/8”) each
Torque 60-65 ft-lbs (80-88 Nm) 35-40 ft-lbs (47-54 Nm)
Hex Key M8 5/16 inch
Sealing Head
Discharge Gland Nut 130 ft-lbs (176 Nm) 200 ft-lbs (271 Nm)
Poppet Retainer Screw(s) 25 in-lbs (2.8 Nm) 50 in-lbs (5.6 Nm)
3-Port Pneumatic Valve
HP Adapter 25 ft-lbs (34 Nm)
1/4-inch Outlet to Drain 25 ft-lbs (34 Nm)
Pneumatic Actuator 5 ft-lbs (7 Nm)
3/8-inch HP Gland Nut 50 ft-lbs (68 Nm)
2-Port Pneumatic Valve
3/8-inch HP Gland Nut 50 ft-lbs (68 Nm)
1/4-inch HP Gland Nut 25 ft-lbs (34 Nm)
Pneumatic Actuator 5 ft-lbs (7 Nm)
9/16”-1/4” HP Bushing 50 ft-lbs (68 Nm)
High Pressure Fittings
1/4-inch Gland Nut 25 ft-lb (34 Nm)
3/8-inch Gland Nut 50 ft-lb (68 Nm)
9/16-inch Gland Nut 110 ft-lb (149 Nm)
