20412989
1-2012/Rev 08
8-1
SECTION 8
ELECTRICAL SYSTEM
8.1 Overview
All SL-V Plus models are equipped with integral motor starter and control circuitry, enclosed in
the electrical panel. The operator controls the machine primarily through a touch-screen control
panel that communicates with the programmable logic controller (PLC). A series of sensors
provide automatic shutdown logic and diagnostics.
Major system components include the electric motor, control panel, high voltage and control
components, and the wiring harness that connects the sensors and solenoid valves to the PLC.
8.2 Optional System Components
The following system options are available at the time of purchase, or as upgrade kits for existing
equipment.
A pressure transducer allows the operating pressure to be viewed from the display panel.
Proportional pressure control allows the operator to select or vary the hydraulic operating
pressure from the control panel or from a remote console.
A modem option permits remote monitoring for troubleshooting and software updates.
A 37-pin amphenol connector, mounted in the side of the electrical enclosure, is available
for all remote connections.
