Section 12
Parts List
20413146
8-2012/Rev 12
12-2
12.2 Index
Part lists are arranged in the following sequence:
Parts List Index
Table Description
Part
Number Page Table Description
Part
Number Page
12-1 100 HP Intensifier Unit 12-4 12-13 Reservoir Assembly 05104153 12-26
12-2 Intensifier Assembly 72122493 12-6 12-14 Bulkhead Pipe Assembly 80079668 12-28
12-3 Hydraulic Cartridge Seal 05146584 12-8 12-15 Cover Assembly 80074768 12-31
12-4 Sealing Head Assembly 80072341 12-9 12-16 Electrical Assembly 49830938 12-33
12-5 Pneumatic Valve/Actuator Assembly 10184760 12-10 12-17 Controls Subassembly 80077845 12-35
12-6 Hydraulic Piston Assembly 05146576 12-12 12-18 Control Panel Configuration 80074156 12-38
12-7 High Pressure Piping, 2L Attenuator 20429831 12-14 12-19 Control Panel Configuration 20493065 12-40
12-8 Low Pressure Water Filter Assembly 80087976 12-16 12-20 Proportional Pressure Control 80075732 12-42
12-9 Hydraulic Power Package 49835846 12-18 12-21 High Pressure Transducer 20431959 12-44
12-10 Motor/Pump Assembly 80076458 12-20 12-22 Redundant Kit 20431316 12-46
12-11 Hydraulic Manifold Assembly 49835796 12-22
12-12 Hydraulic Hose Connections 05142351 12-24
